Electric gangway winch 500 kg - 6 m/min
Model AW 500 ES
| Power supply | Electric |
|---|---|
| WLL lifting top layer | 500 kg |
| Speed at 1st layer | 6.0 m/min |
| Motor power | 1.50 kW |
| Drum capacity | 30 m |
| Extended drum | No |
Product specification AW 500 ES
| Power supply | Electric |
|---|---|
| WLL lifting top layer | 500 kg |
| Holding force | 1500 kg |
| Numbers of layers | 3 |
| Rope diameter | 8 mm |
| Speed at 1st layer | 6.0 m/min |
| Drum capacity | 30 m |
| Motor power | 1.50 kW |
| Motor voltage | 400V AC 3 phase |
| Weight | 85 kg |
| Gearbox type | Wormgear |
| Extended drum | No |
*For more storage, higher / lower speed or change any parameter, please contact with us
Product dimensions AW 500 ES
Series: AW/PW - winches for accomodation and ladder applications
Constructed as required by SOLAS for international shipping, they are equipped with a dynamically and statically self-braking wormgear and emergency hand crank. Every kind may be set for 1 or 2 rope operation and powered via an electric or pneumatic motor. These winches are designed for positioning and holding accommodation and ship-to-shore ladders, vessel-to-vessel ladders as well as offshore applications. Industrial Winch™ has one standard design (PW 550) which was provided to a couple of dredging vessel fleet owners. We have also provided sume customised designs. Do not hesitate to ask about all the available options.
Standard features
- SOLAS compliance
- Self-braking wormgear transmission for the AW series
- Emergency hand crank for the AW series only
- Planetary gear for PW 550
- FEM / ISO class: T3-L3-M4
- 13 meter pilot ladder with 32 fl at steps, 4 spreaders and 4 rubber steps for PW 550
- Two drum supports
- IP 56 TENV motor protection for the AW ES series
- Pneumatic versions with hand control valve
- IP 66 TENV with standstill heating for the PW 550
- IP 66 spindle limit switch for PW 550
- Rotary vane, gear type air or motor for the AW LS series
- Double layer 2-component conservation, colour RAL 5010
- Steel drum (not grooved) with one or two cable fixing point(s) at flange
