Winch brake types: band, disc and failsafe

A winch brake has one essential job: to hold the load securely when the winch is not moving it, and to do so safely. But not all brakes are the same. Winches use different brake types, band, disc and multi-disc, each holding the load in its own way and suited to different duties, and beyond the type there is a more important principle, whether the brake is failsafe. Understanding the brake types and the failsafe idea is part of understanding how a winch holds a load safely, which is as important as how hard it pulls, and it builds on the holding behaviour our note on brake holding force covers.

What a winch brake must do

The brake holds the load when the winch stops, and on a lifting winch it must hold a suspended load securely and indefinitely, while on a lowering duty it may also help control the descent. A good brake holds the rated load with margin, applies and releases cleanly, and does not fade or slip. Many winches actually have two braking functions: a holding brake that secures the load when the winch is stopped, and a control of the descent when lowering, sometimes by the same brake and sometimes by separate means. The brake is therefore not a single simple part but a function that has to be matched to how the winch holds and lowers its load.

The band brake

A band brake uses a flexible band lined with friction material that tightens around a brake drum to hold or slow it. It is mechanically simple and has long been used on winches, and it is well suited to holding a load and to controlling a descent, because the band can be applied progressively. Its simplicity is its strength, with few parts and easy adjustment, and it has served winching for a long time. Its limit is that it is less compact and makes less holding force for its size than a multi-disc brake, so on high force or compact duties other types may be preferred, but for many winches the band brake remains a sound, proven choice.

The disc and multi-disc brake

A disc brake clamps friction plates together to hold the shaft, and a multi-disc brake stacks several plates to make a large holding force in a small, compact package. This is its great strength: a multi-disc brake holds a heavy load securely in a unit far smaller than a band brake of the same capacity, and it can be built into the winch, sealed against dirt and wet. This compact, high force holding makes multi-disc brakes the natural choice for heavy, modern winches where holding force and a compact design both matter, and they are common on hydraulic winches where the brake can be released hydraulically. For high holding force in little space, the multi-disc brake is hard to beat.

Service brake and holding brake

Many winches distinguish between a service brake that controls movement and slows the load, and a holding brake that secures the load when the winch is stopped. The service brake works during operation, helping control a descent, while the holding brake takes over to secure the load at rest. On some winches one brake does both; on others they are separate, each suited to its task. This division matters because controlling a moving load and holding a stationary one are different demands, and a winch that handles both well often uses the right brake for each, which is part of how a winch lowers under control and then holds securely.

The failsafe principle

More important than the brake type is whether it is failsafe. A failsafe brake is spring applied and power released: a spring holds the brake on by default, and power, hydraulic or air, is used to release it. So the brake holds the load unless something actively releases it, and if the power is lost the spring applies the brake and the load is held rather than dropped. This is the same principle as the air winch automatic brake our note on the automatic brake covers, and it applies across brake types. A holding brake that needed power to hold would drop the load on a power failure, so failsafe is essential for safe load holding.

Why power applied brakes are not for holding

The opposite of a failsafe brake is one that needs power to apply and hold, releasing when power is lost. Such a brake is dangerous as a load holding brake, because the very failure you most need it to survive, a loss of power, is when it would let go and drop the load. Power applied brakes have their uses elsewhere, but for holding a load on a winch they are the wrong choice, which is why serious winches use spring applied, failsafe holding brakes. The principle is simple but vital: the brake must hold the load by default and release only when deliberately powered, not the other way round, so a failure leaves the load held.

Matching the brake to the winch

Choosing the brake follows the duty. A simple winch may use a band brake for holding and lowering control; a heavy, compact, modern winch often uses a multi-disc holding brake released hydraulically; and across all of them the holding brake should be failsafe. The brake is sized to hold the rated load with margin, to apply and release cleanly, and to suit how the winch lowers, and its function is proven by testing, the subject of our note on load testing. The honest approach is to match the brake type and the failsafe holding to the duty, which we treat as part of supplying a winch that holds its load safely rather than just pulling it.

A winch that holds safely with us

We build winches with the brake matched to the duty, band or multi-disc, and always failsafe for load holding. See the range in our winch catalogue, and read how the brake holds the load, how the counterbalance valve controls lowering on hydraulic winches, and how the brake is proven by load testing. Tell us the load and the duty, and we will specify a brake that holds the load securely and safely.

Frequently asked questions

What is the difference between a band and a disc winch brake?

A band brake tightens a lined band around a drum and is simple and good for holding and lowering control. A disc or multi-disc brake clamps friction plates together for a large holding force in a compact package. The band suits simple duty, the multi-disc heavy, compact, high force holding.

What is a failsafe winch brake?

A brake that is spring applied and power released: a spring holds it on by default and power releases it. So the brake holds the load unless something actively releases it, and if power is lost the spring applies it and the load is held rather than dropped. Failsafe holding is essential for safe load holding.

Why not use a power applied brake to hold a load?

Because a power applied brake needs power to hold and releases when power is lost, so the very failure you most need it to survive, a loss of power, is when it would drop the load. For holding a load a winch must use a spring applied, failsafe brake that holds by default and releases only when powered.

Do winches have more than one brake?

Often, yes. Many distinguish a service brake that controls movement and slows the load from a holding brake that secures it at rest. Sometimes one brake does both; sometimes they are separate, each suited to its task, because controlling a moving load and holding a stationary one are different demands.
